FIVER FIVER AUTOPARTS CO.,LTD — Chongqing

FIVER AUTOPARTS CO.,LTD

Hyundai A/C compressor

A/C Compressor 97610-H1003/97701-4A370 for Hyundai Satelite
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Hyundai A/C compressor

A/C Compressor 97610-H1003/97701-4A370 for Hyundai Satelite

OE / Part number
97610-H1003, 97701-4A370

A/C Compressor 97610-H1003/97701-4A370 for Hyundai Satelite — aftermarket A/C compressor OE 97610-H1003 supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

modelA/C Compressor manufacturer China / A/C compressor supplier / A/C Compressor for Hyundai / A/C Compressor for Hyundai Satelite
OE / Part number97610-H1003, 97701-4A370
ApplicationApplications: Hyundai H-1 2.5 TDIC/Starex 2.4i 8V/ H-200 2.4i 8V/Satelite 2.4i 8V. 1997-2005

§ 03

Product details

Characters of products from fivercompressor.com
Precision machined ports for OE hose fitment.
Internal pistons are PTFE surface treated for longlife durability;
Robotic weldding for precise and consistent quality;
Internal valves are engineered with light weight aluminum alloy for optimize cooling;
OE connectors are available for most applications, no need reposition or splice wiring during installations;
Bearings structured to withstand tension and stree for maximum durability.

Part Name: A/C Compressor for Hyundai

OE: 97610-H1003/97701-4A370/97701-4A300/97701-4A021

Compressor Type: HS18

Clutch info: 138mm 1PK 12V

Oil type : PAG 46
Oil Quantity : 200ml

Applications:

Hyundai H-1 2.5 TDIC/Starex 2.4i 8V/ H-200 2.4i 8V/Satelite 2.4i 8V. 1997-2005

§ 04

Similar compressors

No.CompressorClutchPulley
