FIVER AUTOPARTS CO.,LTD

Honda A/C compressor

Type DKV14D DKV14D 4PK A/C Compressor 8-97085-896-0 8970858960 for Honda Passport EX/LX V6 3.2L/L4 2.6L 1994-1997 for Acura SLX 1996-1997 for ISUZU… 4PK · 12V
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Honda DKV14D A/C compressor

DKV14D 4PK A/C Compressor 8-97085-896-0 8970858960 for Honda Passport EX/LX V6 3.2L/L4 2.6L 1994-1997 for Acura SLX 1996-1997 for ISUZU Trooper 1992-1997

OE / Part number
8-97085-896-0, 8970858960, 8970753660, 8970792730, 8970811770, 8970835000, 8970858980, 8970954900, 8970961490

AC Compressor for Honda Passport 1994-1997; Acura SLX AC Compressor; Air conditioning compressor for Isuzu Trooper

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Specification, split

Recorded against the compressor type and its OE cross-reference.

Compressor

Compressor TypeDKV14D
Pulley Groove4PK

Clutch and fitment

Coil Voltage12V

§ 02

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 03

Data sheet

Compressor TypeDKV14D
Pulley Groove4PK
Coil Voltage12V
OE / Part number8-97085-896-0, 8970858960, 8970753660, 8970792730, 8970811770, 8970835000, 8970858980, 8970954900, 8970961490

§ 04

Product details

DKV14D 4PK A/C Compressor 8-97085-896-0 8970858960 for Honda Passport EX/LX V6 3.2L/L4 2.6L 1994-1997 for Acura SLX 1996-1997 for ISUZU Trooper 1992-1997

Specifications
TypeCompressor Assy
ModelDKV14D
Grooves4
Clutch Diameter108mm
Voltage12


VEHICLE FITMENT
ACURASLX All Models1996-1997
HONDAPASSPORT 3.2L V6/ 2.6L L41994-1997
ISUZURODEO 3.2L V61993-1998
ISUZURODEO SPORT. 3.2L V62001-2003
ISUZUTROOPER 3.2L V61992-1997



Alternate/OEM Part Number(s): 8970753660, 8970792730, 8970811770, 8970835000, 8970858960, 8970858980, 8970954900, 8970961490
