AC Compressor Assy 38800-PH3-013, 38800PH3013 for Honda Accord
OE 38800-PH3-013, 38800PH3013
FIVER AUTOPARTS CO.,LTD
Honda A/C compressor
Honda Civic AC Compressor assy 38800P00K01,38810-P07-014; 38810-P07-024 Product description: Each unit passes universal testing which includes vacuum, pressure, noise and performance; Charged with a lubricant to reduce internal friction promoting enhanced system performance and longevity; A h
§ 01
A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.
Control valve
Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.
Drive pulley
Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.
Rotor and swash plate
Pistons run on an inclined swash plate; the inclination sets displacement.
Piston and cylinder
Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.
Suction port
Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.
Discharge port
High-pressure gas out to the condenser. Leak tested on every unit.
§ 02
§ 03
Part Name: AC COMPRESSOR (Honda Civic AC Compressor assy 38800P00K01 38810-P07-014 38810-P07-024)
Part Number: 38800P00K01, 38810-P07-014, 38810-P07-024
Applications: Honda CIVIC (EG5,EG8,EH1,EH5,EH9)

§ 04
OE 38800-PH3-013, 38800PH3013
OE 38800-PH3-003, 38800PH3003
OE 38800-PH1-003, 38800PH1003
