Toyota A/C compressor

Type TV12C Supply TV12C AC Compressor 96142-5458 961425458 for Toyota Corolla Coupe 2 Doors 1988-1990 and for Toyota Tercel DLX/DX/STD 1988-1990 5PK/4PK · 12V
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Toyota TV12C A/C compressor

Supply TV12C AC Compressor 96142-5458 961425458 for Toyota Corolla Coupe 2 Doors 1988-1990 and for Toyota Tercel DLX/DX/STD 1988-1990

OE / Part number
96142-5458, 961425458, 16001155-102, 16001155-103

This Compressor is a OE quality replacement for 96142-5458 961425458 for Toyota Corolla Coupe 2 Doors 1988-1990 and for Toyota Tercel DLX/DX/STD 1988-1990, 100% tested to meet OE quality standards

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Specification, split

Recorded against the compressor type and its OE cross-reference.

Compressor

Compressor TypeTV12C
Groove5PK/4PK

Clutch and fitment

Coil Voltage12V

§ 02

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 03

Data sheet

Compressor TypeTV12C
Groove5PK/4PK
Coil Voltage12V
OE / Part number96142-5458, 961425458, 16001155-102, 16001155-103
ApplicationApplications: 1988 Toyota Tercel From May 1988 - With Power Steering [with SWITCH PORT. 4 grooves

§ 04

Product details

Supply TV12C AC Compressor 96142-5458 961425458 for Toyota Corolla Coupe 2 Doors 1988-1990 and for Toyota Tercel DLX/DX/STD 1988-1990

Specifications
Refrigerant TypeR12
Clutch Maximum Diameter145.0 MM
Compressor Mount Hole Quantity4
Pulley Belt TypeSerpentine 5PK
Mounting TypeBolt Tangent
Applications:

1988 Toyota Tercel From May 1988 - With Power Steering [with SWITCH PORT. 4 grooves
1988 Toyota Corolla Coupe and Comp type- TV12C. 5 grooves
1989 Toyota Corolla Coupe and Comp type- TV12C. 5 grooves
1990 Toyota Corolla Coupe and Comp type- TV12C. 5 grooves
1991 Toyota Corolla Coupe and Comp type- TV12C. 5 grooves

1989 Toyota Tercel With Power Steering [TV12C with SWITCH PORT. 4 grooves

1990 Toyota Tercel With Power Steering [TV12C with SWITCH PORT. 4 grooves

Interchange OE Numbers:

142500-2640,142500-2643,1425002640,142500264084,1425002643,142500264384,16001155-101,16001155-102,16001155-103,16001155101,16001155102,16001155103,96142-5458, 961425458
