FIVER AUTOPARTS CO.,LTD

Nissan A/C compressor

KOMPRESSOR 92600-32R01 92600-32R00 92600-D4522 NISSAN BLUEBIRD
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Nissan A/C compressor

KOMPRESSOR 92600-32R01 92600-32R00 92600-D4522 NISSAN BLUEBIRD

OE / Part number
92600-32R01, 92600-32R00, 92600-D4522, 92600-D4521, 92600-D4523, 92600-D4520

KOMPRESSOR 92600-32R01 92600-32R00 92600-D4522 NISSAN BLUEBIRD — aftermarket A/C compressor OE 92600-32R01 supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

OE / Part number92600-32R01, 92600-32R00, 92600-D4522, 92600-D4521, 92600-D4523, 92600-D4520
ApplicationNISSAN BLUEBIRD [T12] 12.1985-02.1990

§ 03

Product details

Part Name: KOMPRESSOR
Part Number: 92600-32R01 92600-32R00 92600-D4522 92600-D4521 92600-D4523 92600-D4520
Application: NISSAN BLUEBIRD [T12] 12.1985-02.1990
Remarks: COMPRESSOR ASSY-COOLER. Applied Model: *CA16S +*CA20S +*CA20E +*CA18T +*CA18D; (01.90 - ...)
