Nissan A/C compressor

KOMPRESSOR 92600-2M260 92600-2M218 92600-2M217 NISSAN ALMERA
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Nissan A/C compressor

KOMPRESSOR 92600-2M260 92600-2M218 92600-2M217 NISSAN ALMERA

OE / Part number
92600-2M260, 92600-2M218, 92600-2M217, 92600-2M216, 92600-2M215, 92600-2M203, 92600-2M202

KOMPRESSOR 92600-2M260 92600-2M218 92600-2M217 NISSAN ALMERA — aftermarket A/C compressor OE 92600-2M260 supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

OE / Part number92600-2M260, 92600-2M218, 92600-2M217, 92600-2M216, 92600-2M215, 92600-2M203, 92600-2M202
ApplicationNISSAN ALMERA [N15] 07.1995-04.2000

§ 03

Product details

Part Name: KOMPRESSOR
Part Number: 92600-2M260 92600-2M218 92600-2M217 92600-2M216 92600-2M215 92600-2M203 92600-2M202
Application: NISSAN ALMERA [N15] 07.1995-04.2000
Remarks: COMPRESSOR ASSY-COOLER. Applied Model: *4S.GA14DE.(GX+SLX) +*3HB.GA14DE.(GX+SLX) +*3HB.S; Specification: F/AIR CON+F/PWR STRG-LINKAGE; (01.99 - 10.99)
