Nissan A/C compressor

COMPRESSOR-COOL 92600-W2110 92600-W2100 92600-V2500 NISSAN DATSUN 810
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Nissan A/C compressor

COMPRESSOR-COOL 92600-W2110 92600-W2100 92600-V2500 NISSAN DATSUN 810

OE / Part number
92600-W2110, 92600-W2100, 92600-V2500, 92600-V2501, 92600-V2502, 92600-D8101, 92600-D8102

COMPRESSOR-COOL 92600-W2110 92600-W2100 92600-V2500 NISSAN DATSUN 810 — aftermarket A/C compressor OE 92600-W2110 supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

OE / Part number92600-W2110, 92600-W2100, 92600-V2500, 92600-V2501, 92600-V2502, 92600-D8101, 92600-D8102
ApplicationNISSAN DATSUN 810 [910] 01.1980-06.1984

§ 03

Product details

Part Name: COMPRESSOR-COOL
Part Number: 92600-W2110 92600-W2100 92600-V2500 92600-V2501 92600-V2502 92600-D8101 92600-D8102
Application: NISSAN DATSUN 810 [910] 01.1980-06.1984
Remarks: COMPRESSOR ASSY-COOLER. Applied Model: *S +*W; (04.81 - 06.81)
