Nissan A/C compressor

COMPRESSOR-COLL 92600-13E11 92600-13E01 92600-13E00 NISSAN BLUEBIRD
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Nissan A/C compressor

COMPRESSOR-COLL 92600-13E11 92600-13E01 92600-13E00 NISSAN BLUEBIRD

OE / Part number
92600-13E11, 92600-13E01, 92600-13E00, 92600-D4520, 92600-D4523, 92600-D4522, 92600-D4521

COMPRESSOR-COLL 92600-13E11 92600-13E01 92600-13E00 NISSAN BLUEBIRD — aftermarket A/C compressor OE 92600-13E11 supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

OE / Part number92600-13E11, 92600-13E01, 92600-13E00, 92600-D4520, 92600-D4523, 92600-D4522, 92600-D4521
ApplicationNISSAN BLUEBIRD [U11] 11.1983-05.1990

§ 03

Product details

Part Name: COMPRESSOR-COLL
Part Number: 92600-13E11 92600-13E01 92600-13E00 92600-D4520 92600-D4523 92600-D4522 92600-D4521
Application: NISSAN BLUEBIRD [U11] 11.1983-05.1990
Remarks: COMPRESSOR ASSY-COOLER. Applied Model: *S.(CA18S+CA20S+CA18T) +*W.(CA20S+CA20E); Specification: W/POWER STEERING; (01.84 - 10.85)
