Toyota A/C compressor

AC Compressor SKI4381S for Lexus RCF, Ford Ranger and Lincoln Continental
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Toyota A/C compressor

AC Compressor SKI4381S for Lexus RCF, Ford Ranger and Lincoln Continental

OE / Part number
SKI4381S

This AC Compressor SKI4381S is suitable for Ford L series truck; Ford Ranger;Ford Transit 350; GMC Canyon; GMC Savana 3500; Infiniti QX70; Lexus RC F; Lincoln Continental brand new replacement parts for aftermarket.

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

modelA/C Compressor for Lexus RCF / AC Compressor for Ford Ranger / air conditioning compressor for Lincoln Continental / AC Compressor for Ford L series truck
OE / Part numberSKI4381S
ApplicationApplications: FORD

§ 03

Product details

AC Compressor SKI4381S for Lexus RCF, Ford Ranger and Lincoln Continental

Applications:

FORD L SERIES TRUCK 1997
FORD RANGER 2017
FORD TRANSIT 150 2017
FORD TRANSIT 350 2017
GMC CANYON 2017
GMC SAVANA 3500 2017
INFINITI QX70 2017
LEXUS RC F 2017
LINCOLN CONTINENTAL 2017

Specifications:

Clutch Included Yes
Clutch Maximum Diameter (IN) 4.953125
Coil Clock Position Wire Lead
Coil Voltage 12
Comp Head Prt Config Rear-Horiz-O-Ring
Compatible Refrigerant Oil Type PAG 100
Compressor Head Type MDA
Compressor Type Sd7h15
Connector Gender Female
Discharge Port Type O-Ring
Distance From Clutch To Mounting Flange (IN) 1.046875
Mounting Hardware? Not Included
Mounting Type Tangent Mount
New or Reman New
O-Ring A Number/Desc [24111] / Mini York Teflon Seal O-Ring
O-Ring A Quantity 2
Pulley Belt Type Serpentine
Pulley Diameter (MM) 125.730
Pulley Groove Quantity 12
Pulley Lip Diameter (IN) 4.953125
Pulley Outside Diameter (IN) 4.953125
Pulley Ridge Diameter (IN) 4.953125
Refrigerant Type R134a
Suction Port Type O-Ring
Terminal Type Packard
Type Sanden/Sankyo
Alternate/OEM Part Number(s): SKI4381S
