FIVER FIVER AUTOPARTS CO.,LTD — Chongqing

FIVER AUTOPARTS CO.,LTD

Nissan A/C compressor

AC COMPRESSOR ASSY 92600-8J03A 92600-8J02B 92600-8J03B NISSAN ALTIMA
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Nissan A/C compressor

AC COMPRESSOR ASSY 92600-8J03A 92600-8J02B 92600-8J03B NISSAN ALTIMA

OE / Part number
92600-8J03A, 92600-8J02B, 92600-8J03B

AC COMPRESSOR ASSY 92600-8J03A 92600-8J02B 92600-8J03B NISSAN ALTIMA — aftermarket A/C compressor OE 92600-8J03A supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

OE / Part number92600-8J03A, 92600-8J02B, 92600-8J03B
ApplicationNISSAN ALTIMA [L31] 03.2004-04.2007

§ 03

Product details

Part Name: A/C Compressor assy
Part Number: 92600-8J03A 92600-8J02B 92600-8J03B
Application: NISSAN ALTIMA [L31] 03.2004-04.2007
Remarks: COMPRESSOR ASSY-COOLER. Applied Model: 4S.QR25DE; (05.06 - 02.07)
