AC COMPRESSOR ASSY MB899776 MR168867 MITSUBISHI STRADA
OE MB899776, MR168867
FIVER AUTOPARTS CO.,LTD
Mitsubishi A/C compressor
AC COMPRESSOR ASSY 7813A040 MITSUBISHI LANCER 06.2001-08.2007 — aftermarket A/C compressor OE 7813A040 supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.
§ 01
A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.
Control valve
Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.
Drive pulley
Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.
Rotor and swash plate
Pistons run on an inclined swash plate; the inclination sets displacement.
Piston and cylinder
Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.
Suction port
Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.
Discharge port
High-pressure gas out to the condenser. Leak tested on every unit.
§ 02
§ 03
§ 04
OE MB899776, MR168867
OE MB917806, MR148623
OE MB878074, MR149347
