VW A/C compressor

AC COMPRESSOR 4F0260805AJ AUDI A6/AVANT
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
VW A/C compressor

AC COMPRESSOR 4F0260805AJ AUDI A6/AVANT

OE / Part number
4F0260805AJ

AC COMPRESSOR 4F0260805AJ AUDI A6/AVANT — aftermarket A/C compressor OE 4F0260805AJ supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

OE / Part number4F0260805AJ
ApplicationAUDI A6/AVANT [A6]2009-2011 / AUDI A6/S6 QUATTRO [A6Q]2009-2011

§ 03

Product details

Part Name: Compressor, air conditioning
Part Number: 4F0260805AJ
Application: AUDI A6/AVANT [A6]2009-2011 / AUDI A6/S6 QUATTRO [A6Q]2009-2011
Remarks: A/C compressor; DENSO
