Mazda A/C compressor

AC COMPRESSOR 1E05-61-450 1E05-61-450A 1E04-61-450 MAZDA 121ECE 1996
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Mazda A/C compressor

AC COMPRESSOR 1E05-61-450 1E05-61-450A 1E04-61-450 MAZDA 121ECE 1996

OE / Part number
1E05-61-450, 1E05-61-450A, 1E04-61-450, 1E03-61-450A, 1E03-61-450, 1E07-61-450, 1E07-61-450A

AC COMPRESSOR 1E05-61-450 1E05-61-450A 1E04-61-450 MAZDA 121ECE 1996 — aftermarket A/C compressor OE 1E05-61-450 supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

OE / Part number1E05-61-450, 1E05-61-450A, 1E04-61-450, 1E03-61-450A, 1E03-61-450, 1E07-61-450, 1E07-61-450A
ApplicationMAZDA 121ECE 1996 [AEDA05] 01.1996

§ 03

Product details

Part Name: Compressor, air conditioning
Part Number: 1E05-61-450 1E05-61-450A 1E04-61-450 1E03-61-450A 1E03-61-450 1E07-61-450 1E07-61-450A
Application: MAZDA 121ECE 1996 [AEDA05] 01.1996
Remarks: COMPRESSOR. A (1E05-61-450A) 1250 960501 - 970101; Period: 01.05.1996 - 01.01.1997;

§ 04

Similar compressors

No.CompressorClutchPulley
