VW A/C compressor

AC COMPRESSOR 191820803 1GD820803A 1GD820803 VOLKSWAGEN JETTA
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
VW A/C compressor

AC COMPRESSOR 191820803 1GD820803A 1GD820803 VOLKSWAGEN JETTA

OE / Part number
191820803, 1GD820803A, 1GD820803, 1GD820803B, 535820803, 1GD820803C, 1GD820803E, 1J0820803K, 1J0820803F, 1JD820803, 1GD820803F

AC COMPRESSOR 191820803 1GD820803A 1GD820803 VOLKSWAGEN JETTA — aftermarket A/C compressor OE 191820803 supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

OE / Part number191820803, 1GD820803A, 1GD820803, 1GD820803B, 535820803, 1GD820803C, 1GD820803E, 1J0820803K, 1J0820803F, 1JD820803, 1GD820803F
ApplicationVOLKSWAGEN JETTA [JE]

§ 03

Product details

Part Name: Compressor, air conditioning
Part Number: 191820803 1GD820803A 1GD820803 1GD820803B 535820803 1GD820803C 1GD820803E 1J0820803K 1J0820803F 1JD820803 1GD820803F
Application: VOLKSWAGEN JETTA [JE]
Remarks: A/C compressor with; electro-magnetic coupling; ABX,ACR

§ 04

Similar compressors

No.CompressorClutchPulley
