Toyota A/C compressor

Toyota Corona/Carina 2 A/C Compressor assy 88320-20400 88320-20370 88320-12460
Compressor assembly line, Chongqing
PRODUCTION PLATECompressor assembly line, Chongqing
Toyota A/C compressor

Toyota Corona/Carina 2 A/C Compressor assy 88320-20400 88320-20370 88320-12460

OE / Part number
88320-20400, 88320-20370, 88320-12460

Toyota Corona/Carina 2 A/C Compressor assy 88320-20400 88320-20370 88320-12460 — aftermarket A/C compressor OE 88320-20400 supplied by FIVER AUTOPARTS CO.,LTD. Send an inquiry for price and availability.

What arrives with every unit

  • TRACEProduction record filed against the order line.
  • TESTVacuum, pressure, noise and performance checked before packing.
  • SHIPExport packing with the packing list in the box.
  • SUPPORTApplication engineering available for fitment questions.

§ 01

Inside the compressor

A sectional drawing of a swash-plate compressor, with the six features that decide whether it holds pressure.

1 2 3 4 5 6
1

Control valve

Varies the swash-plate stroke to hold low-side suction pressure steady under changing load.

2

Drive pulley

Poly-V pulley driven from the engine belt; belt tension and alignment decide clutch life.

3

Rotor and swash plate

Pistons run on an inclined swash plate; the inclination sets displacement.

4

Piston and cylinder

Hardened, honed bores sized against the rotor so the swept volume stays on the drawing.

5

Suction port

Low-pressure refrigerant in. Pressure is verified against the test curve before the unit ships.

6

Discharge port

High-pressure gas out to the condenser. Leak tested on every unit.

§ 02

Data sheet

OE / Part number88320-20400, 88320-20370, 88320-12460
ApplicationToyota Corona/Carina 2

§ 03

Product details

Part Name: A/C Compressor assy
Part Number: 88320-20400 88320-20370 88320-12460
Application: Toyota Corona/Carina 2
AT151R-TLMNS | 1983.10-1987.11 | 4AL | LB | GL | MTM | 5F | RHD | GEN |
AT151R-TLMDS | 1983.10-1985.08 | 4AL | LB | XL | MTM | 5F | RHD | GEN |
AT151L-TEKDS | 1983.10-1987.11 | 4AL | SED | XL | MTM | 4F | LHD | GEN |
AT151L-TLMDSW | 1983.10-1987.11 | 4AL | LB | D
